SPECIFICATIONS
- Broadcast mixer or radio, web & TV production
- 8 in balanced pickups with very low noise preamp
- Compressor limiter on each microphone
- Phantom power
- 4 stereo line inputs
- Interface designed for external telephone insert
- Parametric tone adjustment
- 2 balanced main outputs
- 2 switchable subgroups
- 4 auxiliaries
- Headphone output
- Multi headphone output
- Amplified return diffusers output
TECHNICALS SPECIFICATIONS
| 19 inch | 19-inch racking kit (supplied) |
| 48V phantom power | Yes |
| Number of auxiliaries | 3-4 |
| Number of microphone inputs | 9-12 |
| Number of mono channels | 8 |
| Number of stereo channels | 4 |
| Number of submasters | 2 |
| Headphone output | Yes |
| Integrated audio interface | No |
| Integrated audio player | No |
| Integrated mixer effects | Channel equalizer, channel compression |
| Insert connections | No |
| Type of mixer inputs | Microphone input (XLR), balanced line input (6.35 mm TRS jack), unbalanced line input (RCA), Hi-Z input (6.35 mm TRS jack) |
| Mixer type | Studio radio / webradio mixer |
| Type of mixer outputs | balanced line output (XLR), balanced line output (6.35mm TRS jack), stereo headphone output (6.35mm or 3.5mm TRS jack) |
| Volume adjustment | Faders |
| Weight (including packaging) | 6.6 kg |
| Dimensions (including packaging) | 55 x 50 x 13 cm |
